Parker's Chemical Resistant PTFE hoses have exceptional chemical compatibility and handle temperatures as high as +450°F, except in jacketed designs. PTFE Braided hoses are used in numerous applications including, but not limited to, chemical transfer lines, high temperature general hydraulics, and coolant lines. The PTFE core tube resists moisture and offers the lowest coefficient of friction of any known plastic, therefore minimizing pressure drops and deposits.
Parker 919B PTFE Hoses should be used when conveying non-conducting fluids such as oils, paints, fuels, or steam.
Parker’s stainless steel braided PTFE hoses are available with silicone or polyurethane jackets..
Rinkos:
• Fluid Handling
• Medical
• Naftos lauko aptarnavimas
• Transportation
• Military
• Compressed Gas
Savybės/privalumai:
•PTFE lines provide excellent chemical compatibility for successful chemical transfer between lines
• Handles extreme temperatures from -100°F to +450°F
• Resists moisture
• Low friction minimizes pressure drops and deposits
• Steam cleanable
• Available with extruded silicone jacket to provide a clean, smooth cover (919J)
• Available with non-marring, abrasion-resistant polyurethane jacket to shield the stainless steel wire reinforcement against wear, fraying and contaminants (919U)
Pritaikymai:
• Chemical Transfer Lines
• General Hydraulics
• Compressed Air/Gases
• Adhesive Dispensing
• Aušinimo linijos
• Medical Gases
Techninės specifikacijos:• Use hose type 919B with static-dissipative core tube when conveying non-conducting fluids such as oils, paints, fuels, steam, etc.
• Hoses with covers must be skived prior to fitting attachment
• Burst pressure is 4x max working pressure at 73°F (23°C)
• Hose I.D. is nominal
• Hose O.D. is maximum
• Kitos spalvos galimos pagal užsakymą
| Projektavimo koeficientas: | 4 |
| Dangos spalva: | Rudas, Natūralus, Raudonas |
| Terpė: | Air, Chemicals (Adhesive), Chemicals - Check your fluid compatibility with our catalogue chart., Food & Beverage (Cooking Oil), Industrial Fluids, Water |
| Įvykdytos specifikacijos: | FDA 21 CFR 177.1550 (Natūralus Tube), SAE 100R1, Type 4A, SAE 100R1, Type 4B |
| Suderinama jungtis: | 90 Series, 91 Series, 91N Series |
| Svoris: | 0.09 to 0.58 kg/m, 0.06 to 0.39 lb/ft |
| Vidinis skersmuo: | 3/16 to 1-1/8 inch, 5 to 29 mm |
| Maksimali darbinė temperatūra: | 135 to 232 °C, 275 to 450 °F |
| Minimali darbinė temperatūra: | -40 to -73 °C, -40 to -100 °F |
| Produkto stilius: | Static Dissipative |
| Maksimalus darbinis slėgis: | 69 to 207 bar, 6.9 to 20.7 MPa, 1000 to 3000 psi |
| Išorinis skersmuo: | 0.330 inch, 0.400 inch, 0.460 inch, 0.560 inch, 0.580 inch, 0.660 inch, 0.790 inch, 1.060 inch, 8.2 to 26.9 mm |
| Dydis: | -4 to -20 |
| Pritaikymas: | Chemical Transfer, Fluid Handling, Industrial, Instrumentation, Manufacturing, Medical, Packaging, Pharmaceutical, Transportation |
| Žarnos vidinės vamzdelio medžiaga: | Natūralus Static Dissipative, Polytetrafluoroethylene (PTFE) Static Dissipative |
| Dangos medžiaga: | Silicone, Polyurethane |
| Žarnos armatūros medžiaga: | Braid of Stainless Steel |
| Produktai | Hose Type | Size | Length |
|---|---|---|---|
| 919-3 | SS Braid, Natūralus | -3 | Random |
| 919-4-100 | SS Braid, Natūralus | -4 | 100 ft |
| 919-5-100 | SS Braid, Natūralus | -5 | 100 ft |
| 919-6-100 | SS Braid, Natūralus | -6 | 100 ft |
| 919-8-100 | SS Braid, Natūralus | -8 | 100 ft |
| 919-10-50 | SS Braid, Natūralus | -10 | 50 ft |
| 919-12-50 | SS Braid, Natūralus | -12 | 50 ft |
| 919-16-50 | SS Braid, Natūralus | -16 | Random |
| 919-20 | SS Braid, Natūralus | -20 | Random |
| 919B-4 | SS Braid, Static Dissipative | -4 | Random |
| 919B-5 | SS Braid, Static Dissipative | -5 | Random |
| 919B-6 | SS Braid, Static Dissipative | -6 | Random |
| 919B-8 | SS Braid, Static Dissipative | -8 | Random |
| 919J-4-RED | Silicone Jacket, Natūralus | -4 | Random |
| 919J-5-RED | Silicone Jacket, Natūralus | -5 | Random |
| 919J-6-RED | Silicone Jacket, Natūralus | -6 | Random |
| 919J-8-RED | Silicone Jacket, Natūralus | -8 | Random |
| 919J-10-RED | Silicone Jacket, Natūralus | -10 | Random |
| 919J-12-RED | Silicone Jacket, Natūralus | -12 | Random |
| 919U-4 | Polyurethane Jacket, Natūralus | -4 | Random |
| 919U-6 | Polyurethane Jacket, Natūralus | -6 | Random |
| 919U-8 | Polyurethane Jacket, Natūralus | -8 | Random |
| 919U-12 | Polyurethane Jacket, Natūralus | -12 | Random |
| 919U-16 | Polyurethane Jacket, Natūralus | -16 | Random |
| 919-10 | SS Braid, Natūralus | -10 | Random |
| 919-12 | SS Braid, Natūralus | -12 | Random |
| 919-16 | SS Braid, Natūralus | -16 | Random |
| 919-4 | SS Braid, Natūralus | -4 | Random |
| 919-5 | SS Braid, Natūralus | -5 | Random |
| 919-6 | SS Braid, Natūralus | -6 | Random |
| 919-8 | SS Braid, Natūralus | -8 | Random |
| 919BJ-4-ORG | Silicone Jacket, Static Dissipative | -4 | Random |
| 919BJ-6-ORG | Silicone Jacket, Static Dissipative | -6 | Random |
| 919BJ-8-ORG | Silicone Jacket, Static Dissipative | -8 | Random |
| 919BJ-10-ORG | Silicone Jacket, Static Dissipative | -10 | Random |
| 919BJ-12-ORG | Silicone Jacket, Static Dissipative | -12 | Random |
| 919J-16-RED | Silicone Jacket, Natūralus | -16 | Random |
| 919BJ-16-ORG | Silicone Jacket, Static Dissipative | -16 | Random |
| 919BJ-5-ORG | Silicone Jacket, Static Dissipative | -5 | Random |
