The Parker 387 GlobalCore hose is a constant working pressure hydraulic hose offering 3,000 PSI in all sizes. This light, durable, and easy-to-bend hose meets and exceeds ISO 18752 performance specifications. The 387 hose offers low force-to-flex and delivers full SAE-standard pressure at one-half SAE bend radius, resulting in easier handling and installation. 387 hose also offers a 30% smaller OD by area compared with SAE-standard spiral hose. Compatible with petroleum-based hydraulic fluids and lubricating oils, 387 GlobalCore hose is offered in sizes ranging from ¼-inch to 2 inches in diameter and with three cover options: Standard, ToughCover, and SuperTough.



Turud:

• Transportation

• Military

• Construction

• Agriculture

• Grounds & Building Maintenance

• Waste & Refuse

• Material Handling

• Forestry

• Railroad

• Utility Equipment

• Personal Lift Equipment

• Machine Tool



Omadused/eelised:

• Standard or ToughCover options to prevent abrasion

• Half SAE bend radius for ease of installation and low force to flex

• 30% smaller O.D. by area compared to the SAE spiral hose

• 3,000 PSI constant working pressure in all sizes

• Lighter than the standard SAE spiral hose



Rakendused:

• Petroleum base hydraulic fluids and lubricating oils



Ühilduvad liitmikud:

• 43 series fittings (for sizes -4 to -20)

• 77 series fittings (for sizes -20 to -32)
