Parker’s 580N/588N High Pressure Hose meets SAE 100R8 specifications and, with a lighter weight and smaller O.D. than the 100R2, replaces 100R2 rubber hose wherever greater flexibility, fluid compatibility, and cover durability are required. This high pressure hydraulic hose features a highly developed design, available in twin-line and multi-line constructions, to ensure high performance in hydraulic and pneumatic circuits and systems applications. Offering superior features, such as a reduced weight and improved flexing capabilities, the Parflex 580N/588N High Pressure Hose combines a variety of advantages to fulfill application requirements in expanding fluid handling and industrial pneumatic markets.
Turud:
• Fluid Handling
• Tööstuslik
• Mobiilne seadmestik
Omadused/eelised:
• Twin and multi-line available to fulfill diverse application requirements
• Lighter weight and smaller O.D. than 100R2 for improved handling and routing
• Replaces 100R2 rubber hose wherever greater flexibility, fluid compatibility, and cover durability are required
Rakendused:
• Hydraulic and pneumatic circuits and systems
• Construction Equipment
• Factory Automation
• Machine Tools
• Material Handling Equipment
• Turf Equipment
Sertifikaadid/Vastavus:
• Meets/Exceeds SAE J517 100R8
• DNV-GL Type Approved
• 580N MSHA complaint cover
• 588N Meets SAE J517 for less than 50 micro-amps leakage under 75,000 volts per foot
Tehnilised spetsifikatsioonid:
• Hose 588N has a non-conductive core tube for applications where electric shock is a potential danger for operators
• Hose I.D. is nominal
• Hose O.D. is maximum
| Minimaalne töötemperatuur: | -40 °C, -40 °F |
| Kate värv: | Must, Oranž |
| Juhitav aine: | Air, Industrial Fluids, Lubricants, Petroleum Hydraulic Fluids, Water |
| Täidetud spetsifikatsioonid: | DNG GL, SAE 100R8, SAE J517 (588N) |
| Ühilduv liitmik: | 56 Series |
| Kaal: | 0.31 to 0.79 kg/m, 0.21 to 0.53 lb/ft |
| Maksimaalne töötemperatuur: | 212 °F, 100 °C |
| Suurus: | -8 to -16 |
| Siseläbimõõt: | 1/2 to 1 inch, 13 to 25 mm |
| Maksimaalne töörõhk: | 138 to 241 bar, 13.8 to 24.1 MPa, 2000 to 3500 psi |
| Rakendus: | Agriculture Equipment, Construction Equipment, Fluid Handling, Forestry, Hydraulics, Industrial, Manufacturing |
| Disainifaktor: | 4 |
| Vooliku sisetoru materjal: | Polyamide (PA) |
| Kate materjal: | Polyurethane |
| Vooliku tugevdusmaterjal: | Fiber |
| Toote stiil: | Non-Conductive, Standard |
| Välisläbimõõt: | 0.890 inch, 0.980 inch, 1.470 inch, 1.500 inch, 22.6 to 37.3 mm |
| Minimaalne painderaadiuse: | 6 to 10 inch, 102 to 254 mm |
| Tooted | Hose I.D. (inch) | Hose Type | Notes |
|---|---|---|---|
| 580N-8 | 1/2 | General Purpose | |
| 580N-10 | 5/8 | General Purpose | |
| 580N-12 | 3/4 | General Purpose | |
| 580N-16 | 1 | General Purpose | |
| H580N-16 | 1 | General Purpose | Obsolete |
| 588N-8 | 1/2 | Non Conductive | Do not use for pneumatic applications |
| 588N-10 | 5/8 | Non Conductive | Do not use for pneumatic applications |
| 588N-12 | 3/4 | Non Conductive | Do not use for pneumatic applications |
| 588N-16 | 1 | Non Conductive | Do not use for pneumatic applications |
