Parker Polyflex 2390N Hoses for the Oil & Gas industry are designed for safety, versatility and efficiency, matching the tough requirements and expectations of the market place. Easy winching from drums reduces deployment or replacement times significantly. Long lengths allow operation in significant water depth and the durability of the hose assures maximized service life under extreme conditions.
Turud:
• Nafta ja gaas
• Marine
Omadused/eelised:
• Low dimensional change under pressure
• Sile sisepind madala rõhu jaoks
• Meets or exceeds performance requirements of ISO 13628-5
Rakendused:
• Low volumetric expansion hose.
• Long length subsea umbilical hose.
• V12-V16 used for subsea haydraulic controls
• Long length hot-line hose for BOP Systems
• V91: for working pressure up to 44.5 MPa (6.450 psi)
• V12-V16: for working pressure up to 49 MPa (7.105 psi)
Tehnilised spetsifikatsioonid:
• Core tube : Methanol washed PA11 (V91) and Polyamide (V12-V16)
• Pressure reinforcement : High strength wire
• Cover : PA12 (V91) and Polyurethane (V12-V16)
• Colour: Must (V91), Sinine (V12), Roheline (V13), Kollane (V16)
• Temperature Range: -40°C up to +100°C, max. 70°C for water or methanol based fluids.
| Kaal: | 0.17 to 0.79 lb/ft, 0.25 to 1.17 kg/m |
| Tööstus: | Marine, Oil & Gas |
| Vooliku sisetoru materjal: | Polyamide (PA) |
| Bränd: | Parker |
| Minimaalne töötemperatuur: | -40 °F |
| Maksimaalne töörõhk: | 280 to 490 bar, 4060 to 7105 psi, 28.0 to 49.0 MPa |
| Toote tüüp: | Hydraulic Hose, Transfer Hose, Water Hose |
| Tehnoloogia: | Fluid & Gas Handling |
| Kate materjal: | Polyurethane |
| Konstruktsioonimaterjalid: | Thermoplastic |
| Disainifaktor: | 4:1 |
| Divisjon: | Polymer Hose Division Europe |
| Toote stiil: | Subsea BOP Hose |
| Minimaalne painderaadiuse: | 2.756 to 11.024 inch, 70 to 280 mm |
| Juhitav aine: | Coolants (Glycol), Petroleum Hydraulic Fluids |
| Täidetud spetsifikatsioonid: | API 17E, ISO 13628-5 |
| Ühilduv liitmik: | 8X Series, E3 Series |
| Siseläbimõõt: | 1/4 to 0.992 inch, 6.4 to 25.2 mm |
| Maksimaalne töötemperatuur: | 100 °C (with 8X Series fittings), 55 °C (with E3 Series fittings), 131 °F (with E3 Series fittings), 212 °F (with 8X Series fittings) |
| Rakendus: | Subsea BOP |
| Vooliku tugevdusmaterjal: | High Strength Wire |
| Välisläbimõõt: | 0.528 to 1.375 inch, 13.4 to 34.9 mm |
| Tooted | Hose I.D. (mm) | Kate värv | Maksimaalne töörõhk |
|---|---|---|---|
| 2390N-06V91 | 9.8 | Must | 350 bar |
| 2390N-08V91 | 12.9 | Must | 350 bar |
| 2390N-12V91 | 19.4 | Must | 350 bar |
| 2390N-16V91 | 25.2 | Must | 350 bar |
| 2390N-12V10 | 19.4 | Must | 350 bar |
| 2390N-12V12 | 19.4 | Sinine | 350 bar |
| 2390N-12V13 | 19.4 | Roheline | 350 bar |
| 2390N-12V16 | 19.4 | Kollane | 350 bar |
| 2390N-04V13 | 6.4 | Roheline | 350 bar |
| 2390N-08V10 | 12.9 | Must | 350 bar |
| 2390N-12V03 | 19.6 | Roheline | 350 bar |
