Parflex 56DH diagnostic hose offers the best in class performance by reducing the volume of fluid in the system over -4 rubber hose. This diagnostic hose has a compact O.D., making it the optimal solution for applications where a small diameter hose is desired. It is also a very lightweight hose and, coupled with its good flexibility characteristics, allows for simplified routing and installation in small bore fluid transfer applications. It is often used as a replacement for steel tubing, which is much heavier and stiffer. In addition, it operates in temperatures up to 200°F and at 6,000 psi, withstands a minimum of 200,000 impulse cycles without leakage or malfunction.
Rinkos:
• Pramoninis
• Material Handling
• Kasyba
• Mobili įranga
Savybės/privalumai:
• Lightweight and flexible for easy routing
• Twin or multi-line configurations available to accommodate various application requirements
• Compact O.D. for easier installation in diagnostic equipment and hydraulic and pneumatic systems
Pritaikymai:
• Hydraulic and pneumatic systems where a small diameter hose is desired
• Diagnostic hydraulic lines
• All Mobile and industrial equipment where remote mounting of system pressure is desired
• Statybos įranga
• Ag/Turf equipment
Sertifikatai/Atitiktis:
• MSHA Compliant Cover
Techninės specifikacijos:
• Hose I.D. is nominal
• Hose O.D. is maximum
| Minimali darbinė temperatūra: | -40 °C, -40 °F |
| Projektavimo koeficientas: | 4 |
| Terpė: | Industrial Fluids, Petroleum Hydraulic Fluids, Water, Welding Gases (Technical Gases) |
| Įvykdytos specifikacijos: | MSHA |
| Suderinama jungtis: | SF Series, CY Series |
| Maksimalus darbinis slėgis: | 41.4 MPa, 414 bar, 6000 psi |
| Maksimali darbinė temperatūra: | 200 °F, 93 °C |
| Vidinis skersmuo: | 0.090 inch, 0.140 inch, 2.3 to 3.6 mm |
| Svoris: | 0.02 to 0.03 lb/ft, 0.01 to 0.05 kg/m |
| Pritaikymas: | Construction Equipment, Diagnostics, Industrial, Manufacturing, Material Handling, Pneumatics |
| Žarnos vidinės vamzdelio medžiaga: | Polyamide (PA) |
| Dangos medžiaga: | Polyurethane |
| Žarnos armatūros medžiaga: | Aramid Fiber |
| Minimalus lenkimo spindulys: | 1/4 to 1/2 inch, 6.4 to 13 mm |
| Išorinis skersmuo: | 0.210 inch, 0.320 inch, 5.3 to 8.1 mm |
| Dydis: | -1.5 to -2 |
