| Application: | Thermal management systems |
| Hose I.D. (size): | -4, -6, -8, -10, -12, -16 |
| Media: | air, water (including PCW), coolant solutions |
| Cover Color: | Black, Blue, Red |
| Cover Material: | Synthetic rubber |
| Hose Cover Type: | Smooth |
| Hose Inner Tube Material: | Black EPDM Peroxide cured |
| Hose Reinforcement Material: | One fiber braid |
| Hose Inside Diameter: | 1/4 thru 1 inch, 6.4 thru 25.4 mm |
| Hose Outside Diameter: | 0.50 to 1.28 inch, 12.1 to 32.6 mm |
| Maximum Operating Temperature: | 212 °F, 100 °C |
| Minimum Operating Temperature: | -40 °F, -40 °C |
| Maximum Operating Pressure: | Up to 150 psi, Up to 10 bar, Up to 1.03 MPa |
| Minimum Bend Radius: | 1, 1.2, 6 inch, 25.4, 30, 152.4 mm |
| Specifications Met: | UL94 V-0 Flame Resistance Rating |
| Compatible Fitting: | 82 Series Fittings |
| Design Factor: | 4:1 |
| Vacuum Pressure Rating: | 15 inch-Hg, 381 mm-Hg |
| Weight: | 0.08 to 0.31 lb/ft, 0.12 to 0.46 kg/m |
